规格 (in) | W.L.L (lbs) | Proof Load (lbs) | Min Ultimate Load (lbs) | Kg/pc | Handle Length | 尺寸(in) | ||||||
A | B | D | E | E1 | F1 | F1 | ||||||
1/4-5/16 | 2200 | 4400 | 7800 | 1.6 | 7.16 | 7.16 | 0.89 | 1.77 | 16.22 | 21.62 | 17.79 | 0.35 |
5/16-3/8 | 5400 | 10800 | 19000 | 4.773 | 13.42 | 13.92 | 1.3 | 2.6 | 22.64 | 30.64 | 25.24 | 0.51 |
5/16-3/8 | 6600 | 10800 | 19800 | 4.891 | 13.42 | 13.92 | 1.3 | 2.6 | 22.64 | 30.64 | 25.24 | 0.51 |
3/8-1/2 | 9200 | 18400 | 33000 | 5.864 | 13.92 | 13.92 | 1.3 | 2.6 | 24.13 | 32.13 | 27.04 | 0.59 |
1/2-5/8 | 13000 | 26000 | 46000 | 6.536 | 13.92 | 13.92 | 1.3 | 2.6 | 26.45 | 34.45 | 30.07 | 0.74 |
